DA03-11CGKWA

Kingbright
RoHS
RoHS RoHS compliant
Package 10-DIP (0.400, 10.16mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description KINGBRIGHT DA03-11CGKWA 7-Segment LED Display, Mechanically Rugged, 2, 7.62 mm, Green, Common Anode, 16 mcd, 20 mA
PDF
/
Inventory: 9379
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Character Height 7.62mm
Height 15.494mm

Technical

Character Width 4mm
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Segments 7
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 574nm
Millicandela Rating 16mcd
Luminous Intensity 16 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation-Max 75mW
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.610 Hx0.591W x 0.283 D 15.50mmx15.00mmx7.20mm
Published 2010
Packaging Tube

Physical

Package / Case 10-DIP (0.400, 10.16mm)
Mount Through Hole

Supply Chain

Factory Lead Time 8 Weeks
