CC56-11SRWA
RoHS
RoHS compliant
RoHS compliantPackage 36-DIP Module (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 660NM RED 4DIG 0.56" TH
PDF
/
Inventory: 1399
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 18.9992mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 4
Forward Voltage-Max 2.5V
Display Type 7-Segment Clock
Forward Current-Max 0.03A
Wavelength - Peak 660nm
Luminous Intensity 40 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.85V
Power Dissipation-Max 75mW
Operating Temperature (Max) 85°C
Number of Functions 4
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx1.980W x 0.319 D 19.00mmx50.30mmx8.10mm
Published 2011
Packaging Tube
Physical
Package / Case 36-DIP Module (0.600, 15.24mm)
Supply Chain
Factory Lead Time 12 Weeks
