CC56-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 36-DIP Module (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Kingbright CC56-11EWA 4 Digit High Efficiency Red LED Display
PDF
/
Inventory: 2974
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 36-DIP Module (0.600, 15.24mm)
Technical
Packaging Tube
Published 2011
Size / Dimension 0.748 Hx1.980W x 0.319 D 19.00mmx50.30mmx8.10mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 4
Operating Supply Voltage 2V
Power Dissipation-Max 75mW
Element Configuration Common Cathode
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 2.4 mcd
Millicandela Rating 5.8mcd
Wavelength - Peak 627nm
Power Consumption 75mW
Display Type 7-Segment Clock
Forward Voltage-Max 2.5V
Number of Characters 4
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dimensions
Height 18.9992mm
Character Height 14.22mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
