BC56-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories HI EFF RED DIFFUSED 3 DIGIT
PDF
/
Buying Options
Total Price: USD $5.32
Unit Price: USD $5.324
≥1 USD $5.324
≥10 USD $3.763012
≥100 USD $3.081945
≥500 USD $2.598138
≥1000 USD $2.383119
≥3000 USD $2.284568
Inventory: 1696
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 14.22mm
Height 37.592mm
Technical
Character Width 14.224mm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 3
Forward Voltage-Max 2.5V
Display Type 7-Segment
Wavelength - Peak 627nm
Millicandela Rating 5.8mcd
Luminous Intensity 2.4 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Operating Supply Voltage 2V
Number of Functions 3
Subcategory LED Displays
HTS Code 8541.40.20.00
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 1.480 Hx0.748W x 0.319 D 37.60mmx19.00mmx8.10mm
Published 2011
Packaging Tube
Physical
Number of Pins 28
Package / Case 28-DIP (0.600, 15.24mm)
Supply Chain
Factory Lead Time 12 Weeks
Alternative Model
