BA56-12SURKWA

Kingbright
RoHS
RoHS RoHS compliant
Package 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories .56 3-DIGIT RED LED DISPLAY
PDF
/
Buying Options
Total Price: USD $5.32
Unit Price: USD $5.324
≥1 USD $5.324
≥10 USD $3.763012
≥100 USD $3.081945
≥500 USD $2.598138
≥1000 USD $2.383119
≥3000 USD $2.284568
Inventory: 1147
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Character Height 14.2mm
Height 37.592mm

Technical

Character Width 8mm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Segments 7
Number of Characters 3
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 645nm
Millicandela Rating 73mcd
Luminous Intensity 73 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 1.95V
Element Configuration Common Anode
Number of Functions 3
HTS Code 8541.40.20.00
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.480 Hx0.748W x 0.319 D 37.60mmx19.00mmx8.10mm
Published 2010
Packaging Tube

Physical

Package / Case 12-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 8 Weeks
