ACSA02-41SGWA-F01
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 0.2" SGL 568NM GRN SMD
PDF
/
Buying Options
Total Price: USD $2.97
Unit Price: USD $2.9656
≥1 USD $2.9656
≥10 USD $1.97472
≥100 USD $1.519672
Inventory: 1197
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 10-SMD, No Lead
Manufacturer Package Identifier ACSA02-41SGWA-F01
Technical
Packaging Tape & Reel (TR)
Published 2011
Size / Dimension 0.315 Hx0.272W x 0.118 D 8.00mmx6.90mmx3.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Number of Functions 1
Operating Supply Voltage 2.2V
Element Configuration Common Anode
Power Dissipation 62.5mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 10mA
Current - Test 20mA
Luminous Intensity 1.4 mcd
Millicandela Rating 3.9mcd
Wavelength - Peak 565nm
Power Consumption 62.5mW
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.20 5.08mm
Common Pin Common Anode
Character Width 5.08mm
Dimensions
Height 3.25mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
