MAN72A
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CA 14-Pin PDIP
PDF
/
Inventory: 8726
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 7.62mm
Height 18.7452mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Forward Voltage-Max 2V
Reverse Voltage 6V
Display Type 7-Segment
Wavelength - Peak 660nm
Millicandela Rating 0.35mcd
Luminous Intensity 350 μcd
Current - Test 20mA
Forward Current 240mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 480mW
Element Configuration Common Anode
Number of Elements 8
Operating Supply Voltage 2V
Depth 9.8mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE, HIGH RELIABILITY
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.738 Hx0.386W x 0.200 D 18.75mmx9.80mmx5.08mm
Published 2006
Packaging Bulk
Physical
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
