MAN6940
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG DUAL CC RED RHDP .56"
PDF
/
Buying Options
Total Price: USD $1.82
Unit Price: USD $1.815741
≥1 USD $1.815741
≥200 USD $0.724721
≥500 USD $0.701089
≥1000 USD $0.689273
Inventory: 3525
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Viewing Area (height) 14.22mm
Height 19.05mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Reverse Voltage 6V
Display Type 7-Segment
Wavelength - Peak 635nm
Luminous Intensity 2.2 mcd
Current - Test 20mA
Forward Current 480mA
Voltage - Forward (Vf) (Typ) 2.5V Max
Power Dissipation 1.2W
Element Configuration Common Cathode
Number of Elements 16
Operating Supply Voltage 2.5V
Depth 19.05mm
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.750 Hx0.985W x 0.315 D 19.05mmx25.02mmx8.00mm
Published 1997
Packaging Tube
Physical
Number of Pins 18
Package / Case 18-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
