MAN6640
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG DUAL CC ORN RHDP .56"
PDF
/
Buying Options
Total Price: USD $12.35
Unit Price: USD $12.34715
≥1 USD $12.34715
≥10 USD $10.1308
≥100 USD $9.81445
≥500 USD $9.4981
≥1000 USD $9.18175
Inventory: 9209
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 18-DIP
Number of Pins 18
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.750 Hx0.985W x 0.315 D 19.05mmx25.02mmx8.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Additional Feature IC COMPATIBLE, HIGH RELIABILITY
Number of Functions 2
Depth 19.05mm
Operating Supply Voltage 2.5V
Number of Elements 16
Element Configuration Common Cathode
Power Dissipation 1.2W
Voltage - Forward (Vf) (Typ) 2.5V Max
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 480mA
Current - Test 20mA
Luminous Intensity 2.2 mcd
Wavelength - Peak 630nm
Display Type 7-Segment
Reverse Voltage 6V
Number of Characters 2
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dimensions
Height 19.05mm
Viewing Area (height) 14.22mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
