ELST-405SYGWA/S530-E2
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD, No Lead, 11 Pads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY ALLNGAP SGL DIGIT SMD
PDF
/
Buying Options
Total Price: USD $10.95
Unit Price: USD $10.950899
≥1 USD $10.950899
≥200 USD $4.369331
≥700 USD $4.223599
≥1400 USD $4.15139
Inventory: 7716
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 13.0048mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 3
Display Type 7-Segment
Forward Current-Max 0.025A
Wavelength - Peak 575nm
Luminous Intensity 9 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 3
HTS Code 8541.40.20.00
Color Yellow-Green
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.512 Hx1.157W x 0.148 D 13.00mmx29.40mmx3.75mm
Published 2005
Packaging Tape & Reel (TR)
Physical
Package / Case 12-SMD, No Lead, 11 Pads
Supply Chain
Factory Lead Time 12 Weeks
