ELSS-505SYGWA/S530-E2
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY ALLNGAP SGL DIGIT SMD
PDF
/
Inventory: 6025
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 15.494mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.51 13.00mm
Number of Characters 1
Display Type 7-Segment
Forward Current-Max 0.025A
Wavelength - Peak 575nm
Luminous Intensity 10.8 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Color Yellow-Green
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.610 Hx0.482W x 0.148 D 15.50mmx12.25mmx3.75mm
Published 2005
Packaging Tape & Reel (TR)
Physical
Package / Case 10-SMD, No Lead
Supply Chain
Factory Lead Time 12 Weeks
