ELSS-405SYGWA/S530-E2
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Brilliant Yellow Green CC 10-Pin SMD T/R
PDF
/
Inventory: 9545
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Package / Case 10-SMD, No Lead
Number of Pins 10
Technical
Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 0.512 Hx0.386W x 0.148 D 13.00mmx9.80mmx3.75mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Yellow-Green
Number of Functions 1
Depth 15mm
Operating Temperature (Min) -40°C
Number of Elements 8
Power Dissipation-Max 60mW
Element Configuration Common Cathode
Power Dissipation 60W
Voltage - Forward (Vf) (Typ) 2V
Forward Current 25mA
Current - Test 20mA
Luminous Intensity 10.6 mcd
Wavelength - Peak 575nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.39 10.00mm
Common Pin Common Cathode
Dominant Wavelength 573 nm
Dimensions
Height 13.0048mm
Viewing Area (height) 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
