ELSF-406SYGWA/S530-E2

Everlight Electronics Co Ltd
RoHS
RoHS RoHS compliant
Package 12-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY QUAD DIGIT 0.39" YLW/GRN
PDF
/
Inventory: 8707
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Package / Case 12-SMD, No Lead
Number of Pins 12

Technical

Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 0.512 Hx1.543W x 0.148 D 13.00mmx39.20mmx3.75mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Yellow-Green
Number of Functions 4
Power Dissipation-Max 60mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 10.8 mcd
Wavelength - Peak 575nm
Forward Current-Max 0.025A
Display Type 7-Segment
Number of Characters 4
Digit/Alpha Size 0.39 10.00mm
Common Pin Common Anode
Dominant Wavelength 573 nm

Dimensions

Height 13.0048mm
Viewing Area (height) 10mm

Compliance

RoHS Status ROHS3 Compliant
