ELS-321SURWA/S530-A3
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY SGL DIGIT 0.3" HYPER RED
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.202949
≥1 USD $0.202949
≥10 USD $0.164782
≥30 USD $0.148437
≥100 USD $0.128021
Inventory: 9600
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 18.9992mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Forward Voltage-Max 2.4V
Display Type 7-Segment
Forward Current-Max 0.025A
Wavelength - Peak 632nm
Luminous Intensity 11 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Subcategory LED Displays
Additional Feature HIGH RELIABILITY
Color Red
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx0.398W x 0.205 D 19.00mmx10.10mmx5.20mm
Published 2013
Packaging Tube
Physical
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Supply Chain
Factory Lead Time 12 Weeks
