RoHS
/
Package 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY QUAD DIGIT INGAN CREE
PDF
/
Inventory: 3049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case 12-DIP (0.600, 15.24mm)

Technical

Packaging Tube
Published 2009
Size / Dimension 0.748 Hx1.984W x 0.315 D 19.00mmx50.40mmx8.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Blue
Power Dissipation-Max 130mW
Voltage - Forward (Vf) (Typ) 3.5V
Current - Test 20mA
Forward Voltage 3.5V
Luminous Intensity 6.4 mcd
Millicandela Rating 6.4mcd
Wavelength - Peak 468nm
Display Type 7-Segment
Number of Characters 4
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode

Dimensions

Height 18.9992mm
Width 50.3936mm

Compliance

RoHS Status RoHS Compliant
