ELD-515SURWA/S530-A3

Everlight Electronics Co Ltd
RoHS
RoHS RoHS compliant
Package 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description 7-segment LED-display red 12.7 mm THT, ELD515SURWA/S530-A3, Everlight Electronics
PDF
/
Inventory: 2974
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 20 Weeks

Physical

Package / Case 12-DIP (0.600, 15.24mm)

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 18.9992mm

Technical

Common Pin Common Cathode
Digit/Alpha Size 0.50 12.70mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 632nm
Luminous Intensity 15 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 2
Additional Feature HIGH RELIABILITY
Color Red
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx0.984W x 0.315 D 19.00mmx25.00mmx8.00mm
Published 2006
Packaging Tube
