EADCT056BA2
RoHS
RoHS compliant
RoHS compliantPackage 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
THRU-HOLE 7-SEGMENT BLU
PDF
/
Buying Options
Total Price: USD $4.88
Unit Price: USD $4.878736
≥1 USD $4.878736
≥195 USD $1.947031
≥494 USD $1.881386
≥1001 USD $1.849876
Inventory: 2291
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 12-DIP (0.600, 15.24mm)
Technical
Packaging Tube
Published 2014
Size / Dimension 0.748 Hx1.484W x 0.315 D 19.00mmx37.70mmx8.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Blue
HTS Code 8541.40.20.00
Number of Functions 3
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 110mW
Voltage - Forward (Vf) (Typ) 3.3V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 17.6 mcd
Wavelength - Peak 468nm
Forward Current-Max 0.025A
Display Type 7-Segment
Number of Characters 3
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Anode
Dimensions
Height 18.9992mm
Compliance
RoHS Status ROHS3 Compliant
