EADCT056AA2
RoHS
RoHS compliant
RoHS compliantPackage 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
THRU-HOLE 7-SEGMENT AMB
PDF
/
Buying Options
Total Price: USD $5.25
Unit Price: USD $5.2516
≥1 USD $5.2516
≥195 USD $2.095388
≥494 USD $2.025805
≥1001 USD $1.991669
Inventory: 9820
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 18.9992mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 3
Display Type 7-Segment
Forward Current-Max 0.025A
Wavelength - Peak 611nm
Luminous Intensity 12.5 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 3
HTS Code 8541.40.20.00
Color Orange
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.748 Hx1.484W x 0.315 D 19.00mmx37.70mmx8.00mm
Published 2014
Packaging Tube
Physical
Package / Case 12-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
