EADCS056RA3
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
THRU-HOLE 7-SEGMENT RED
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.54397
≥1 USD $1.54397
≥200 USD $0.617063
≥480 USD $0.596057
≥1000 USD $0.585553
Inventory: 6521
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 18.9992mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Display Type 7-Segment
Forward Current-Max 0.025A
Wavelength - Peak 650nm
Luminous Intensity 12.5 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Color Red
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.748 Hx0.492W x 0.315 D 19.00mmx12.50mmx8.00mm
Published 2014
Packaging Tube
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
