EADCS030OA2
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
THRU-HOLE 7-SEGMENT ORG
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.382914
≥1 USD $2.382914
≥208 USD $0.95054
≥494 USD $0.91903
≥988 USD $0.903275
Inventory: 7816
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 18.9992mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Display Type 7-Segment
Forward Current-Max 0.025A
Wavelength - Peak 621nm
Luminous Intensity 17.6 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Color Orange
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.748 Hx0.398W x 0.205 D 19.00mmx10.10mmx5.20mm
Published 2014
Packaging Tube
Physical
Package / Case 14-DIP (0.300, 7.62mm), 11 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
