EADCD054GA1
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
THRU-HOLE 16-SEGMENT GRN
PDF
/
Buying Options
Total Price: USD $5.7
Unit Price: USD $5.701925
≥1 USD $5.701925
≥200 USD $2.275256
≥500 USD $2.199108
≥1000 USD $2.162346
Inventory: 4957
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 18-DIP (0.600, 15.24mm)
Technical
Packaging Tube
Published 2014
Size / Dimension 0.835 Hx0.988W x 0.303 D 21.20mmx25.10mmx7.70mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Yellow-Green
Number of Functions 2
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 60mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type 14 SEG ALPHANUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 4.5 mcd
Wavelength - Peak 575nm
Display Type 14-Segment, Alphanumeric
Number of Characters 2
Digit/Alpha Size 0.54 13.72mm
Common Pin Common Cathode
Dimensions
Height 21.209mm
Compliance
RoHS Status ROHS3 Compliant
