EADCD040RA1
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
THRU-HOLE 7-SEGMENT RED
PDF
/
Buying Options
Total Price: USD $2.88
Unit Price: USD $2.87919
≥1 USD $2.87919
≥200 USD $1.148788
≥500 USD $1.110713
≥1000 USD $1.092333
Inventory: 8127
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 16.002mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 632nm
Luminous Intensity 15 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 2
Color Red
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.630 Hx0.795W x 0.276 D 16.00mmx20.20mmx7.00mm
Published 2014
Packaging Tube
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
