EADCD030RA2
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm), 9 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
THRU-HOLE 7-SEGMENT RED
PDF
/
Buying Options
Total Price: USD $2.08
Unit Price: USD $2.082259
≥1 USD $2.082259
≥192 USD $0.831066
≥512 USD $0.803495
≥992 USD $0.789053
Inventory: 6856
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm), 9 Leads
Technical
Packaging Tube
Published 2014
Size / Dimension 0.591 Hx0.610W x 0.283 D 15.00mmx15.50mmx7.20mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Red
Number of Functions 2
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 60mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 6.4 mcd
Wavelength - Peak 632nm
Display Type 7-Segment
Number of Characters 2
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Anode
Dimensions
Height 15.0114mm
Compliance
RoHS Status ROHS3 Compliant
