HDSP-U513-KL000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
7-Segment 1 SMART/NORMAL 7SEG NUMERIC LED DISPLAY Green LED Character Numeric Display Module 2.5V 10mA 105mW 6.8mcd
PDF
/
Buying Options
Total Price: USD $2.95
Unit Price: USD $2.95355
≥1 USD $2.95355
≥10 USD $2.42345
≥100 USD $2.34745
≥500 USD $2.2724
≥1000 USD $2.1964
Inventory: 1103
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 8mm
Height 10.9982mm
Technical
Dominant Wavelength 571 nm
Common Pin Common Cathode
Digit/Alpha Size 0.31 8.00mm
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 566nm
Luminous Intensity 6.8 mcd
Current - Test 10mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 105mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 2.3V
Depth 7.1mm
Number of Functions 1
Subcategory LED Displays
Color Green
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
Published 2014
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.209, 5.30mm)
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
