HDSP-U311
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Yellow CA 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 1320
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Viewing Area (height) 8mm
Height 10.9982mm
Technical
Dominant Wavelength 586 nm
Common Pin Common Anode
Digit/Alpha Size 0.31 8.00mm
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 583nm
Millicandela Rating 2.74mcd
Luminous Intensity 2.74 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 80mW
Element Configuration Common Anode
Number of Elements 8
Depth 7.1mm
Number of Functions 1
Subcategory LED Displays
Color Yellow
Min Operating Temperature -20°C
Max Operating Temperature 90°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
Published 2014
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.209, 5.30mm)
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
