HDSP-U113
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $5.76
Unit Price: USD $5.764
≥1 USD $5.764
≥10 USD $4.07264
≥100 USD $3.335816
≥500 USD $2.812146
≥1000 USD $2.579412
≥3000 USD $2.472747
Inventory: 1937
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.209, 5.30mm)
Number of Pins 10
Technical
Packaging Tube
Published 2000
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 90°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 7.1mm
Operating Supply Voltage 1.8V
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 37mW
Voltage - Forward (Vf) (Typ) 1.7V
Forward Current 20mA
Current - Test 5mA
Luminous Intensity 3.6 mcd
Wavelength - Peak 645nm
Power Consumption 37mW
Display Type 7-Segment
Reverse Voltage 15V
Forward Voltage-Max 2.2V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.31 8.00mm
Common Pin Common Cathode
Dominant Wavelength 637 nm
Character Width 4mm
Dimensions
Height 10.9982mm
Viewing Area (height) 8mm
Character Height 8mm
Compliance
RoHS Status ROHS3 Compliant
