HDSP-U101
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-U101 7-Segment LED Display, 1, 8 mm, Red, Common Anode, 3.6 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $4.36
Unit Price: USD $4.3648
≥1 USD $4.3648
≥10 USD $3.085632
≥100 USD $2.52736
≥500 USD $2.130586
≥1000 USD $1.954269
≥3000 USD $1.87345
Inventory: 1166
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.209, 5.30mm)
Number of Pins 10
Technical
Packaging Tube
Published 2004
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 90°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 7.1mm
Operating Supply Voltage 1.6V
Number of Elements 8
Element Configuration Common Anode
Power Dissipation 37mW
Voltage - Forward (Vf) (Typ) 1.7V
Forward Current 20mA
Current - Test 5mA
Luminous Intensity 3.6 mcd
Wavelength - Peak 645nm
Power Consumption 37mW
Display Type 7-Segment
Reverse Voltage 15V
Forward Voltage-Max 2.2V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.31 8.00mm
Common Pin Common Anode
Dominant Wavelength 637 nm
Character Width 4mm
Dimensions
Height 10.9982mm
Viewing Area (height) 8mm
Character Height 8mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
