HDSP-N106
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm), 14 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Red 637nm .8in 7 Segment
PDF
/
Inventory: 945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Display Height 20mm
Technical
Common Pin Universal
Digit/Alpha Size 0.80 20.32mm
Number of Characters +/-1 (overflow)
Display Type 7-Segment
Forward Current-Max 0.015A
Wavelength - Peak 645nm
Millicandela Rating 3.5mcd
Current - Test 5mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation-Max 37mW
Configuration SEPARATE, 0.5 DIGIT WITH DECIMAL POINT
Operating Temperature (Min) -20°C
Operating Temperature (Max) 100°C
Reach Compliance Code compliant
Number of Functions 0.5
HTS Code 8531.20.00.40
Color Red
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 1.090 Hx0.786W x 0.330 D 27.69mmx19.96mmx8.38mm
Published 2006
Packaging Bulk
Physical
Package / Case 18-DIP (0.600, 15.24mm), 14 Leads
