HDSP-N105
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Red 637nm .8in 7 Segment
PDF
/
Buying Options
Total Price: USD $41.21
Unit Price: USD $41.2129
≥1 USD $41.2129
≥10 USD $33.8162
≥100 USD $32.75885
≥500 USD $31.70245
≥1000 USD $30.64605
Inventory: 1157
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 20.32mm
Height 27.686mm
Technical
Dominant Wavelength 637 nm
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Reverse Voltage 15V
Display Type 7-Segment
Wavelength - Peak 645nm
Luminous Intensity 3.5 mcd
Current - Test 5mA
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 37mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 1.8V
Depth 19.96mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 1.090 Hx0.786W x 0.330 D 27.69mmx19.96mmx8.38mm
Published 2006
Packaging Bulk
Physical
Number of Pins 12
Package / Case 18-DIP (0.600, 15.24mm), 12 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
