HDSP-K511
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Panel 2DIGIT 16LED Green CA 18-Pin DIP
PDF
/
Buying Options
Total Price: USD $3.53
Unit Price: USD $3.5288
≥1 USD $3.5288
≥10 USD $2.49656
≥100 USD $2.0933
Inventory: 1149
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 14.22mm
Height 17.018mm
Technical
Dominant Wavelength 571 nm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Reverse Voltage 50V
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 566nm
Millicandela Rating 2.5mcd
Luminous Intensity 2.5 mcd
Forward Current 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 105mW
Element Configuration Common Anode
Number of Elements 16
Operating Supply Voltage 2.1V
Depth 17.02mm
Number of Functions 2
Subcategory LED Displays
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.670 Hx0.990W x 0.315 D 17.02mmx25.15mmx8.00mm
Published 2006
Packaging Bulk
Physical
Number of Pins 18
Package / Case 18-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
