HDSP-H8E1
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEGMENT RED
PDF
/
Buying Options
Total Price: USD $2.26
Unit Price: USD $2.264753
≥1 USD $2.264753
≥324 USD $0.904588
≥648 USD $0.874391
≥972 USD $0.858637
Inventory: 9457
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Package / Case 16-DIP (0.600, 15.24mm)
Technical
Packaging Bulk
Published 2012
Size / Dimension 1.091 Hx0.787W x 0.394 D 27.70mmx20.00mmx10.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin (Sn)
Color Red
Power Dissipation-Max 52mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 30 mcd
Wavelength - Peak 634nm
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Anode
Dimensions
Height 27.7114mm
Compliance
RoHS Status ROHS3 Compliant
