HDSP-H8A1
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEGMENT DEEP RED
PDF
/
Inventory: 4020
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 27.7114mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 644nm
Luminous Intensity 29 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 52mW
Color Red
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 1.091 Hx0.787W x 0.394 D 27.70mmx20.00mmx10.00mm
Published 2012
Packaging Bulk
Physical
Package / Case 16-DIP (0.600, 15.24mm)
Supply Chain
Factory Lead Time 16 Weeks
Alternative Model
