HDSP-H2A1
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (2.370, 60.20mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEGMENT DEEP RED
PDF
/
Inventory: 6868
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Package / Case 10-DIP (2.370, 60.20mm)
Technical
Packaging Bulk
Published 2012
Size / Dimension 2.744 Hx1.882W x 0.472 D 69.70mmx47.80mmx12.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin (Sn)
Color Red
Power Dissipation-Max 208mW
Voltage - Forward (Vf) (Typ) 4V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 95 mcd
Wavelength - Peak 644nm
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 2.30 58.42mm
Common Pin Common Anode
Dimensions
Height 69.6976mm
Compliance
RoHS Status ROHS3 Compliant
