HDSP-H211-GH000

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories Red 626nm 0.56in 7 Segment
PDF
/
Inventory: 8761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Reverse Voltage 30V
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 635nm
Luminous Intensity 2.8 mcd
Current - Test 20mA
Forward Current 30mA
Power Dissipation 105mW
Element Configuration Common Anode
Number of Elements 8
Operating Supply Voltage 2V
Depth 17.02mm
Number of Functions 1
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
Published 2001
Packaging Bulk

Dimensions

Height 17.018mm
Viewing Area (height) 14.22mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant

Physical

Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
