HDSP-H103-DE000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CC 10-Pin DIP
PDF
/
Inventory: 4145
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 17.02mm
Operating Supply Voltage 1.7V
Number of Elements 8
Power Dissipation-Max 37mW
Element Configuration Common Cathode
Power Dissipation 37mW
Forward Current 15mA
Current - Test 5mA
Luminous Intensity 1 mcd
Millicandela Rating 4.2mcd
Wavelength - Peak 645nm
Display Type 7-Segment
Reverse Voltage 15V
Forward Voltage-Max 2.2V
Number of Characters 1
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dominant Wavelength 637 nm
Dimensions
Height 17.018mm
Viewing Area (height) 14.22mm
Character Height 14.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
