HDSP-H103
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-H103 7-Segment LED Display, 1, 14.2 mm, Red, Common Cathode, 4.2 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $4.28
Unit Price: USD $4.2768
≥1 USD $4.2768
≥10 USD $3.02456
≥100 USD $2.47727
≥500 USD $2.088372
≥1000 USD $1.91554
≥3000 USD $1.836331
Inventory: 1370
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 14.2mm
Viewing Area (height) 14.22mm
Height 17.018mm
Technical
Character Width 7.8mm
Dominant Wavelength 637 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Segments 7
Number of Characters 1
Reverse Voltage 15V
Display Type 7-Segment
Wavelength - Peak 645nm
Luminous Intensity 4.2 mcd
Current - Test 5mA
Forward Current 20mA
Power Dissipation 37mW
Element Configuration Common Cathode
Power Dissipation-Max 37mW
Number of Elements 8
Operating Supply Voltage 1.7V
Depth 17.02mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
Published 2001
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
