HDSP-G501
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Broadcom HDSP-G501 2 Digit 7-Segment LED Display, CA Green 3.5 mcd RH DP 10.16mm
PDF
/
Inventory: 3565
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Display Height 10mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 2
Display Type 7-Segment
Forward Current-Max 0.03A
Wavelength - Peak 566nm
Millicandela Rating 3.5mcd
Current - Test 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation-Max 105mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Reach Compliance Code compliant
Number of Functions 2
Subcategory LED Displays
Color Green
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 0.670 Hx0.900W x 0.240 D 17.02mmx22.86mmx6.10mm
Packaging Bulk
Physical
Package / Case 18-DIP (0.600, 15.24mm)
