HDSP-F513
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Green CC 10-Pin DIP
PDF
/
Buying Options
Total Price: USD $3.69
Unit Price: USD $3.68531
≥1 USD $3.68531
≥200 USD $1.470448
≥400 USD $1.421871
≥1000 USD $1.398239
Inventory: 1267
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.300, 7.62mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.508 Hx0.385W x 0.250 D 12.90mmx9.79mmx6.36mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Green
Subcategory LED Displays
Number of Functions 1
Depth 9.79mm
Operating Supply Voltage 2.1V
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 105mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 10mA
Luminous Intensity 3 mcd
Millicandela Rating 3mcd
Wavelength - Peak 566nm
Power Consumption 105mW
Display Type 7-Segment
Reverse Voltage 50V
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 0.40 10.16mm
Common Pin Common Cathode
Dominant Wavelength 571 nm
Dimensions
Height 12.9032mm
Viewing Area (height) 10.16mm
Compliance
RoHS Status ROHS3 Compliant
