HDSP-F403
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Orange CC 10-Pin DIP Tube
PDF
/
Inventory: 6413
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10.16mm
Height 12.9032mm
Technical
Dominant Wavelength 603 nm
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 30V
Display Type 7-Segment
Wavelength - Peak 600nm
Millicandela Rating 1.2mcd
Luminous Intensity 1.2 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 105mW
Element Configuration Common Cathode
Power Dissipation-Max 105mW
Number of Elements 8
Operating Supply Voltage 2V
Depth 9.79mm
Number of Functions 1
Subcategory LED Displays
Color Orange
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.508 Hx0.385W x 0.250 D 12.90mmx9.79mmx6.36mm
Published 2014
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
