HDSP-F211
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Hi-Eff. Red CA 10-Pin DIP
PDF
/
Buying Options
Total Price: USD $4.26
Unit Price: USD $4.259048
≥1 USD $4.259048
≥200 USD $1.700206
≥400 USD $1.642438
≥1000 USD $1.614867
Inventory: 1179
Minimum: 1
-
+
Technical Details
Technical
Operating Supply Voltage 2V
Number of Elements 8
Depth 9.79mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.508 Hx0.385W x 0.250 D 12.90mmx9.79mmx6.36mm
Published 2006
Packaging Bulk
Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 30V
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 635nm
Millicandela Rating 1.2mcd
Luminous Intensity 1.2 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 105mW
Element Configuration Common Anode
Physical
Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm)
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10.16mm
Height 12.9032mm
