HDSP-F158
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm), 7 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module Overflow 5LED Red CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $5.4
Unit Price: USD $5.399958
≥1 USD $5.399958
≥200 USD $2.155782
≥400 USD $2.083572
≥1000 USD $2.048124
Inventory: 5430
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10.16mm
Height 12.9032mm
Technical
Dominant Wavelength 637 nm
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Characters +/-1 (overflow)
Forward Voltage-Max 2.2V
Reverse Voltage 15V
Display Type 7-Segment
Wavelength - Peak 645nm
Millicandela Rating 15mcd
Luminous Intensity 15 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.8V
Power Dissipation 96mW
Element Configuration Common Cathode
Number of Elements 5
Depth 9.79mm
Number of Functions 0.5
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.508 Hx0.385W x 0.250 D 12.90mmx9.79mmx6.36mm
Published 2014
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm), 7 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
