HDSP-F103
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED DISPLAY, 10MM, RED, CC
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.5552
≥1 USD $3.5552
≥10 USD $2.516096
≥100 USD $2.10936
Inventory: 7795
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 10mm
Viewing Area (height) 10.16mm
Height 12.9032mm
Technical
Character Width 5.59mm
Background Color Grey
Dominant Wavelength 637 nm
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.2V
Reverse Voltage 15V
Display Type 7-Segment
Power Consumption 37mW
Wavelength - Peak 645nm
Millicandela Rating 3.9mcd
Luminous Intensity 3.9 mcd
Forward Current 5mA
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 37mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 1.8V
Depth 9.79mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.508 Hx0.385W x 0.250 D 12.90mmx9.79mmx6.36mm
Published 2006
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
