HDSP-E106
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Red 637nm 0.43in
PDF
/
Buying Options
Total Price: USD $10.73
Unit Price: USD $10.72835
≥1 USD $10.72835
≥10 USD $8.8027
≥100 USD $8.52815
≥500 USD $8.25265
≥1000 USD $7.97715
Inventory: 10802
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Display Height 10.9mm
Technical
Common Pin Universal
Digit/Alpha Size 0.43 11.00mm
Number of Characters +/-1 (overflow)
Display Type 7-Segment
Forward Current-Max 0.015A
Wavelength - Peak 645nm
Millicandela Rating 3.9mcd
Current - Test 5mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation-Max 37mW
Configuration SEPARATE, 0.5 DIGIT WITH DECIMAL POINT
Operating Temperature (Min) -20°C
Operating Temperature (Max) 100°C
Reach Compliance Code compliant
Number of Functions 0.5
HTS Code 8531.20.00.40
Color Red
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 0.750 Hx0.500W x 0.250 D 19.05mmx12.70mmx6.35mm
Published 2006
Packaging Bulk
Physical
Package / Case 14-DIP (0.300, 7.62mm), 12 Leads
