HDSP-E101
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 10.9MM CA RED RHD
PDF
/
Buying Options
Total Price: USD $5.24
Unit Price: USD $5.236
≥1 USD $5.236
≥10 USD $3.70128
≥100 USD $3.031732
≥500 USD $2.555802
≥1000 USD $2.344294
≥3000 USD $2.247344
Inventory: 201
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Number of Pins 11
Technical
Packaging Tube
Published 2006
Size / Dimension 0.750 Hx0.500W x 0.250 D 19.05mmx12.70mmx6.35mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 12.7mm
Operating Supply Voltage 1.8V
Number of Elements 8
Element Configuration Common Anode
Power Dissipation 37mW
Voltage - Forward (Vf) (Typ) 1.7V
Forward Current 15mA
Current - Test 5mA
Luminous Intensity 3.9 mcd
Wavelength - Peak 645nm
Power Consumption 37mW
Display Type 7-Segment
Reverse Voltage 15V
Number of Characters 1
Digit/Alpha Size 0.43 11.00mm
Common Pin Common Anode
Dominant Wavelength 637 nm
Character Width 10.9mm
Dimensions
Height 19.05mm
Viewing Area (height) 10.92mm
Character Height 10.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
