HDSP-E100

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description Displays Module 1DIGIT 8LED Red CA 11-Pin DIP
PDF
/
Inventory: 5484
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Common Pin Common Anode
Digit/Alpha Size 0.43 11.00mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 645nm
Millicandela Rating 3.9mcd
Current - Test 5mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation-Max 37mW
Operating Temperature (Min) -20°C
Reach Compliance Code compliant
Number of Functions 1
Subcategory LED Displays
Color Red
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 0.750 Hx0.500W x 0.250 D 19.05mmx12.70mmx6.35mm
Published 2006
Packaging Bulk

Physical

Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
