HDSP-C8G3
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.600, 15.24mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 0.80 SGL DGT CC GRN TH
PDF
/
Inventory: 2809
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 14-DIP (0.600, 15.24mm), 10 Leads
Number of Pins 12
Technical
Packaging Tube
Published 2010
Size / Dimension 1.091 Hx0.787W x 0.394 D 27.70mmx20.00mmx10.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Color Green
Additional Feature HIGH RELIABILITY
Subcategory LED Displays
Number of Functions 1
Depth 20mm
Operating Temperature (Min) -40°C
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 62.5mW
Voltage - Forward (Vf) (Typ) 2.25V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 5 mcd
Millicandela Rating 5mcd
Wavelength - Peak 565nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Cathode
Dominant Wavelength 569 nm
Dimensions
Height 27.7114mm
Viewing Area (height) 20.4mm
Character Height 20.4mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
