HDSP-C8E1
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.600, 15.24mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 0.80 SGL DGT CA RED TH
PDF
/
Inventory: 8194
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 20.4mm
Viewing Area (height) 20.4mm
Height 27.7114mm
Technical
Character Width 11mm
Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.80 20.32mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.3V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 640nm
Luminous Intensity 4.8 mcd
Current - Test 20mA
Forward Current 25mA
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 50mW
Element Configuration Common Anode
Power Dissipation-Max 57.5mW
Number of Elements 8
Depth 20mm
Number of Functions 1
Subcategory LED Displays
Additional Feature HIGH RELIABILITY
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 1.091 Hx0.787W x 0.394 D 27.70mmx20.00mmx10.00mm
Published 2011
Packaging Tube
Physical
Number of Pins 12
Package / Case 14-DIP (0.600, 15.24mm), 10 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
