HDSP-C5L3
RoHS
/
Package 10-DIP (0.600, 15.24mm), 8 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
BROADCOM LIMITED HDSP-C5L3 7-Segment LED Display, Orange, 20 mA, 2.15 V, 4 mcd, 1, 13.1 mm
PDF
/
Inventory: 5992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm), 8 Leads
Number of Pins 10
Technical
Packaging Tube
Published 2010
Size / Dimension 0.693 Hx0.488W x 0.272 D 17.60mmx12.40mmx6.90mm
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Color Orange
Additional Feature HIGH RELIABILITY
Subcategory LED Displays
Number of Functions 1
Depth 17.6mm
Reach Compliance Code unknown
Operating Temperature (Min) -40°C
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 57.5mW
Voltage - Forward (Vf) (Typ) 2.15V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 4 mcd
Millicandela Rating 4mcd
Wavelength - Peak 610nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.3V
Number of Characters 1
Digit/Alpha Size 0.52 13.21mm
Common Pin Common Cathode
Dominant Wavelength 605 nm
Dimensions
Height 17.6022mm
Viewing Area (height) 13.1mm
Character Height 13.1mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
