HDSP-C5E1
RoHS
/
Package 10-DIP (0.600, 15.24mm), 8 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
BROADCOM LIMITED HDSP-C5E1 7-Segment LED Display, Red, 20 mA, 2 V, 4 mcd, 1, 13.1 mm
PDF
/
Inventory: 5159
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Character Height 13.1mm
Viewing Area (height) 13.1mm
Height 17.6022mm
Technical
Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.52 13.21mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 640nm
Millicandela Rating 4mcd
Luminous Intensity 4 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 50mW
Element Configuration Common Anode
Power Dissipation-Max 57.5mW
Number of Elements 8
Reach Compliance Code unknown
Depth 17.6mm
Color Red
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.693 Hx0.488W x 0.272 D 17.60mmx12.40mmx6.90mm
Published 1996
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm), 8 Leads
Mount Through Hole
