HDSP-C5A3
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm), 8 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-C5A3 7-Segment LED Display, 1, 13.1 mm, Red, Common Cathode, 4 mcd, 20 mA
PDF
/
Inventory: 5564
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm), 8 Leads
Number of Pins 10
Technical
Packaging Tube
Published 2010
Size / Dimension 0.693 Hx0.488W x 0.272 D 17.60mmx12.40mmx6.90mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature HIGH RELIABILITY
Subcategory LED Displays
Number of Functions 1
Depth 17.6mm
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 50mW
Voltage - Forward (Vf) (Typ) 1.85V
Forward Current 20mA
Luminous Intensity 4 mcd
Millicandela Rating 16mcd
Wavelength - Peak 660nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.52 13.21mm
Common Pin Common Cathode
Dominant Wavelength 643 nm
Character Width 7.62mm
Dimensions
Height 17.6022mm
Viewing Area (height) 13.1mm
Character Height 13.1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
